SENSOR; FUEL LEVEL; ADJUSTABLE; 240 OHM EMPTY TO 33 OHM FULL; SWING-ARM TYPE
This universal fuel level sensor from AutoMeter is the perfect solution for custom made fuel tanks and installations where the original liquid level sensor is unable to be used. Engineered for top down, drop-in mounting orientation with user-adjustable geometry, this sensor can be configured for tanks with overall depths between 5 and 24 inches and provides an output of 240 ohms Empty to 33 ohms Full.
This universal fuel level sensor from AutoMeter is the perfect solution for custom made fuel tanks and installations where the original liquid level sensor is unable to be used. Engineered for top down, drop-in mounting orientation with user-adjustable geometry, this sensor can be configured for tanks with overall depths between 5 and 24 inches and provides an output of 240 ohms Empty to 33 ohms Full.
- For 240 Ohm Empty/33 Ohm Fuel Gauge Models
- Adjustable for 5 - 24 In. Deep Tank
- Fits Standard SAE 5 Hole Top Mounting Flange
| Attributes | |
| Adapters Included | Yes |
| Add-On Part | N/A |
| Adjustable | Yes |
| Adjustable Length | Yes |
| Analog Or Digital | Analog |
| ASIN | B00062YWV0 |
| Block Adapter Included | No |
| California Proposition 65 | WARNING: Cancer - www.P65Warnings.ca.gov |
| Country of Origin (Primary) | TW |
| Emission Code | Legal US |
| Fuel Line Adapter Included | No |
| Gauge Adapter Included | No |
| Harmonized Tariff Code (Schedule B) | 9026900000 |
| Hazardous Material Code | N |
| Illuminated | Yes |
| Life Cycle Status Code | Available to Order |
| Liquid Filled | No |
| Mounting Hardware Included | Yes |
| NAFTA Preference Criterion Code | 9 |
| Number of Bolt Holes | 5 |
| SDR Required Flag | N |
| Voltage | 8-18 V |
| Warranty Time | 12 |
| GTIN | 00046074032622 |
